Compact Double Action Damping Cylinder With Flow Speed Controller

Name: Compact Double Action Damping Cylinder With Flow Speed Controller
Brand: FLUIDAC or OEM
Price: 10 USD

Place of Origin : Ningbo China(Mainland)

Brand Name : FLUIDAC or OEM

Certification : ISO9001

Model Number : DP-40-100

MOQ : 1 piece

Price : USD10--

Packaging Details : Boxes, Cartons,Wooden cases,Pallets

Delivery Time : Within 20 days after receiving payment or deposit

Payment Terms : TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal

Supply Ability : 2000 Pieces Per month

Motion Pattern : Double action

Operating pressure range : 0.25~1.0MPa

Pressure Endurance : 1.5MPa

Product name : Damping Cylinder

Port size : G/18",G1/4",G3/8"

Speed Range : 0~100mm/s

Contact Now

Compact Double Action Damping Cylinder With Flow Speed Controller
DP series compact double action damping cylinder szie 32~100 e.g DP-40-100 with speed controller regulating

Quick Detail:

DP series damping cylinder can parallel installing with pneumatic cylinder,the total length is shorter than Hydro-pneumatic damping cylinder which can save sapce effective.
Air and oil will not mix,flow speed controller can adjust the flow so that cylinder can work smoothly
Inner parts have the oil feeder device design,no need to feed oil from outside

Applications:

DP series damping cylinder used widely in the plastic injection machinery and automation machanical equipment where the motion speed adjustable and steady speed required.

Specifications:

ORDERING CODE
DP	40	100
DP:Standard cylinder	Bore Size	Stroke
	32:32mm
	40:40mm
	50:50mm
	63:63mm
	80:80mm
	100:100mm

SPECIFICATION
Bore size(mm)	32	40	50	63	80	100
working Fluids	YA-N32 Hydraulic Oil
Motion Pattern	Double action
Pressure Endurance (Air cylinder)	1.5MPa
Operating pressure range (Air Cylinder)	0.25~1.0MPa
Ambient Temperature	0~60ºC
Speed Range	0~100mm/s
Port size	G/18	G1/4	G1/4	G3/8	G3/8	G1/2

Compact Double Action Damping Cylinder With Flow Speed Controller
Pneumatic air cylinder,Hydro-Pneumatic cylinder,Damping cylinder
